Advanced AF-6600 - APPENDIX B: Electrical Connections

Version 16.10 AF-6600 AF-5000 Series Install Manual 226
APPENDIX B: Electrical Connections
EFIS MAIN CONNECTOR
Pin
Pin Name
I/O
1
MASTER POWER
IN
2
MASTER GROUND
IN
3
MASTER GROUND
IN
4
SERIAL #3 – TX
OUT
5
SERIAL #3 – RX
IN
6
7
8
INPUT #3
IN
9
SERIAL #1 - GROUND
IN
10
SERIAL #1 – TX
OUT
11
Serial #0 TXD
OUT
12
13
SERIAL #2 – TX
OUT
14
WARNING LIGHT
OUT
15
MASTER POWER
IN
16
AUDIO GROUND
OUT
17
INPUT #1
IN
18
EFIS AUDIO
OUT
19
20
INPUT #2
IN
21
SERIAL #2/#3 - GROUND
OUT
22
SERIAL #1 - RX
IN
23
Serial #0 – RXD
IN
24
Serial #0 - GROUND
OUT
25
SERIAL #2 - RX
IN
