Version 16.10 AF-6600 AF-5000 Series Install Manual 97
Garmin GNC-255
The AF-5000 will send/receive data from a GNC255 on any configured EFIS Serial Port. The EFIS can get
VOR/LOC/GS data from the GNC255 and can set the OBS setting on the GNC255. The EFIS can remote
tune the radio frequencies on a GNC255.
EFIS Serial Port #3 Example
EFIS Main Cable GNC-255 P2001 44 Pin Connector
Pin 4 TXD --------------- Pin 16 RX
Pin 5 RXD --------------- Pin 1 TX
Pin 21 GND --------------- Pin 31 GND
The Indicator Head Type setting should be set to SERIAL, IO mode: NMEA in the GNC255. This will
enable the OBS to be set from the GNC255 buttons and from the EFIS. Enter Calibration mode by cycling
power while holding the ENT key
Garmin GTR-225
The AF-5000 will send/receive data from a SL40 on any configured EFIS Serial Port. The EFIS can remote
tune the radio frequencies on a SL40.
EFIS Serial Port #3 Example
EFIS Main Cable SL40 15 Pin Connector
Pin 4 TXD --------------- Pin 10 RX
Pin 5 RXD --------------- Pin 3 TX
Pin 21 GND --------------- Pin 11 GND
No setup is required in the SL40 Radio,
The EFIS serial port should be configured as GTR/GTN-2XX. You should not select a NAV/G
