Version 16.10 AF-6600 AF-5000 Series Install Manual 261
AF-6600 / AF-5000 ARINC Output
Overview
The AF-5000 when connected to an AFS-ARINC, SV-ARINC-429, AF-ACM-FUSE or AF-ACM-ECB will send a series of
ARINC labels via the output port on the supported device. All labels conform to the GAMA Publication NO. 11 - ARINC
429, General Aviation Subset.
Output Labels - AFS-ARINC
100 - Course
104 - Vertical Speed
117 - Vertical Deviation
121 - Roll Steering
204 - Baro Corrected Altitude
312 - Ground Speed
314 - True Heading
320 - Magnetic Heading
Output Labels - SV-ARINC-429, AF-ACM-FUSE and AF-ACM-ECB
100 - Course
104 - Vertical Speed
105 - Selected Heading
117 - Vertical Deviation
121 - Roll Steering
203 - Pressure Altitude
204 - Baro Corrected Altitude
312 - Ground Speed
314 - True Heading
320 - Magnetic Heading
324 - Current Pitch Attitude
AF-6600 FADC1 RS-232 Data
• Indicated Airspeed
• Pressure Altitude
• Outside Air Temp
• Magnetic Heading
• Fuel Flow
• Fuel Used
• Fuel Remaining
• Baro Corrected
• Altitude Baro Setting
