□ After the engine has started, verify oil pressure and temperature. If none is indicated
SHUT DOWN the engine. Verify all wiring and consult your local A&P, the engine
manufacturer, and/or AFS technical support.
□ Verify all engine indications are correct per your engine manufacturers manual
Before First Flight
□ Verify you have the latest system software and mapping data (if applicable) - Visit the
AFS Website for latest software and map data.
□ Weight & Balance page updated with your aircrafts data
□ Checklist pages updated with information from your aircraft manufacturer
□ Magnetometer Alignment completed on all screens with an AHRS installed (See video on AFS
website Support Forum)
□ EFIS AOA Calibration Checklist completed
□ Pitot/Static check completed from an authorized FAA Repair Station.
□ EFIS and autopilot gains are set per the installation manual
In-Flight Configuration
□ Verify airspeed and altitude indicate correctly
□ Verify heading indicates correctly using a backup whiskey compass for reference
□ Test navigation sources and verify they function properly
□ If an autopilot is installed and coupled to the EFIS, check its functions
After First Flight
□ Calibrate Fuel Flow K-Factor (See Installation Manual)
