Version 16.10 AF-6600 AF-5000 Series Install Manual 126
If you are using our Advanced Control Module (ACM) the Elevator Trim, Aileron Trim, and Flap position will
be wired to the ACM and NOT Wired to the SV-EMS-220.
DB-37 Connector (Engine Sensors)
Pin
EMS 37-pin Harness Wire Color
Sensor
1
Red
Optional Aithre CO Detector input
2
Yellow or Unwired
Optional Aithre Tank PSI Detector input
3
Black
Ground
4
Violet/Blue
Carb Temperature (Skyview Input #1)
5
Black
Ground
6
White/Yellow
Oil pressure
7
White/Brown
Oil temperature
8
Brown
Fuel pressure
9
Brown/Blue
Flap Position
10
Brown/Yellow
Elevator Trim
11
Orange
Aileron Trim (dsub 9 Pin 2)
12
Yellow
Rudder Trim / Coolant Temperature
(dsub 9 Pin 3)
13
Black
Ground (dsub 9 Pin 5)
14
Yellow
Fuel flow
15
Red
+8V Fuel Flow & Amps Hall Transducer Power.
(*Must have SV-EMS Network Pin 7 jumper to Pin 5)
16
Black
Ground
17
Black
Ground
18
White/Red
+5V Aux Out 300ma
19
White/Black
Fuel Flow Input 2
20
Orange/Brown
Tank 1 – Float Sensor Only
21
Orange/Blue
Tank 2 – Float Sensor Only
22
Violet/Yellow
Tank 3 or Capacitance Tank 1
23
Violet/Green
Tank 4 or Capacitance Tank 2
24
Orange/Green
Ammeter shunt +
25
Orange/Violet
Ammeter shunt -
26
Green/Red
Manifold Pressure
27
Open
Turbo Inlet 1 Temp +
28
Open
Turbo Inlet 1 Temp -
29
Yellow/Green
Not Used (Skyview Alarm )
30
Black
Signal Ground (dsub 9 Pin 5)
31
White/Orange
Ammeter Hall Effect
32
White/Green
Standard RPM LEFT
33
White/Blue
Standard RPM Right
34
Blue
Low Voltage RPM Left (<12 Volts)
35
Green
Low Voltage RPM Right (<12Volts)
36
Blue or Unwired
Turbo Inlet Temp 2 +
37
Green or Unwired
Turbo Inlet Temp 2 -
