Version 16.10 AF-6600 AF-5000 Series Install Manual 131
Rotax 912 ULS Carbureted
Below are suggested sensor connections for a Rotax 912 ULS Carbureted engine connected to an SV-
EMS-220 EMS module.
Pin
EMS D37F Harness
Wire Color
Sensor (with Dynon Avionics P/N if applicable)
1
Red
Battery voltage (voltmeter input)
2
Yellow or Unwired
No connection
3
Black
Ground
4
Violet/Blue
Rotax CHT or oil (801-10-1)
5
Black
Ground
6
White/Yellow
Rotax oil pressure (Honeywell or Rotax P/N 456180) *Do not use AFS
Interface module
7
White/Brown
Rotax CHT or oil (801-10-1)
8
Brown
Fuel pressure P/N 101690-000
9
Brown/Blue
Heated AOA/Pitot Probe status (contact input)
10
Brown/Yellow
No connection
11
Orange
No connection
12
Yellow
Flaps position potentiometer
13
Black
Ground
14
Yellow
Fuel flow P/N 100403-003
15
Red
Fuel flow power P/N 100403-003 / Oil pressure (Honeywell and Rotax
P/N 456180 only) sensor power (*Must have SV-EMS Network Pin 7
jumper to Pin 5)
16
Black
Ground
17
Black
Ground
18
White/Red
Manifold Pressure Sensor Power (+5 volt) / Kavlico Pressure Sensors
19
White/Black
No connection
20
Orange/Brown
Fuel level left (resistive)
21
Orange/Blue
Fuel level right (resistive)
22
Violet/Yellow
Rotax CHT or oil (801-10-1)
23
Violet/Green
Elevator position potentiometer
24
Orange/Green
Ammeter shunt + P/N 100412-000
25
Orange/Violet
Ammeter shunt - P/N 100412-000
26
Green/Red
Manifold Pressure P/N 100434-000
27
Open
No connection
28
Open
No connection
29
Yellow/Green
Optional External Alarm Indicator
30
Black
No connection
31
White/Orange
Optional AMPS 2 Hall Sensor
32
White/Green
RPM
33
White/Blue
No connection
34
Blue
No connection
35
Green
No connection
36
Blue or Unwired
No connection
