Version 16.10 AF-6600 AF-5000 Series Install Manual 177
If you have a Capstan or RV-10 Pitch Servo
you will get a WARNING about servo
traveling more than 120 degrees.
• Press YES if you have an RV-10 or Capstan
Servo
• Press NO if you only have Servo with an arm.
If the Pitch and Roll Servos calibrated correctly you should get a SUCCESS message.
• Press SAVE to save the Servo Calibration
