Version 16.10 AF-6600 AF-5000 Series Install Manual 59
AF-INTERCOM
-2S Pin
AF-5000
AF-INTERCOM-2S
Function
Notes
1
N/A
Master Ground In /
Master Shield Ground.
The shields of all
shielded audio cables
should be connected
to this pin.
2
N/A
Microphone / PTT
Ground
Pilot and Copilot
3
N/A
Copilot Microphone
4
N/A
Auxiliary Mono Muting
Input
This audio signal
mutes when audio
signals are received on
other non-muting
inputs and radio
inputs. Use this input
for NON critical audio
signals.
5
N/A
LED Dimmer Input
6
AF-5000 D25 Pin 18
Stereo Non-Muting
(EFIS) Audio Input
This audio signal does
not mute, and is
typically used to
receive audio from AF-
5000 or other EFIS
system with stereo
output.
7
AF-COM 425 #2 Pin 10
Radio 2 or Other Aux
Non-Muting Audio Input
This audio signal does
not mute. Typically
used for a second
COM, a NAV radio, or
other mono avionics
alerts.
8
N/A
Copilot Headphones Left
9
N/A
Pilot Headphones Left
10
N/A
Pilot Push-To-Talk Switch Input
11
N/A
Stereo Music In Right
This input is over-
ridden by the Music In
jack on the AF-
INTERCOM-2S
12
AF-COM-425 #1 Pin 5 AF-
COM-425#2 Pin 5
Push-To-Talk Output
If two radios are used,
this signal must be
switched between the
two radios so that only
ONE radio transmits at
a time.
13
N/A
Power In
