Version 16.10 AF-6600 AF-5000 Series Install Manual 65
The figures on the following pages show recommended panel cutouts, mounting hole patterns, and
mechanical dimension for the SV-COM-PANEL/V (vertical) and SV-COM-PANEL/H (horizontal). Use
these diagrams to plan for the space required by the display.
To mount a SV-COM-PANEL, cut the opening in your panel, drill out the mounting holes, install
nutplates, and use the included mounting screws to fasten the display to the panel.
The SV-COM-PANEL is shipped with #6-32 hex-drive round head fasteners. Fasteners are 5/8” long and
require a 5/64” hex drive tool. AFS recommends fastening the included mounting screws to nut plates
installed behind the panel. If access behind the panel allows, standard #6-32 lock nuts or nuts with lock
washers can be used. Do not rivet the SV-COM-PANEL to the panel as this will hinder future removal if
necessary.
The following installation procedure should be followed to install the Dynon/Trig remote transceiver
module, remembering to allow adequate space for installation of cables and connectors.
If you are installing two COM radios, it is acceptable to co-locate the two transceiver modules.
Select a position in the aircraft for the SV-COM-T25 or SV-COM-T8 Transceiver
that is not too close to any high external heat source. (The Transceiver is not a significant heat
source itself and does not need to be kept away from other devices for this reason).
Avoid sharp bends and placing the cables too near to the aircraft control cables.
Secure the SV-COM-T25 or SV-COM-T8 Transceiver to the aircraft via the three (3) mounting
holes in the transceiver tray. The unit should be mounted to a flat surface.
Additional items you will require for installation of SV-COM-RADIO, but which are not include:
Nutplates for mounting AF-COM-PANEL to the panel
Circuit breaker or fuse for power to SV-COM-T25 or SV-COM-T8 Transceiver
Power wires to SV-COM-T25 or SV-COM-T8 Transceiver
SV-COM-T25 or SV-COM-T8 Transceiver to AF-COM-PANEL wiring
Advanced-SV Network cables to connect the AF-COM-PANEL to Advanced-SV Network
COM Antenna, coaxial cable, terminated to Male TNC connector. The SV-COM-T25 or SV-COM-
T8 Transceiver is compatible with aircraft COM antennas commonly available.
