10 1100 Series FD Reference Manual
Instrument Layout 258
Early Maintenance Feedback (EMF) 259
EMF Counters 259
Using the EMF Counters 261
8 Theory of Operation
Electronics 264
Detector Main Board (FLM) 265
Detector Frontend Board (FLF) 269
Detector Lamp Supply Board (FLL) 273
Firmware Description 274
Firmware Updates 275
Raw Data Conversion to Fluorescence (LU) Units 276
Data flow for chromatographic output 277
Data flow for spectral output 278
Spectra Acquisition Modes 281
Optional Interface Boards 282
BCD Board 283
LAN Board 284
Interfaces 285
Analog Signal Output 286
GPIB Interface 286
CAN Interface 286
Remote Interface 287
RS-232C 288
Setting the 8-bit Configuration Switch 290
GPIB Default Addresses 291
Communication Settings for RS-232C Communication 292
Forced Cold Start Settings 293
