114 1100 Series FD Reference Manual
4 Troubleshooting and Test Functions
Test Functions
The light path is shown in Figure 42.
Figure 42 Schematic of the Light Path
PMT
Reference
Diode
Excitation Grating
Emission Grating
Flow Cell or
Cuvette
Flash Tube
Mirror
Diffuser
