204 1100 Series FD Reference Manual
6 Identifying Parts and Materials
Optical Unit Assembly
Tabl e 25 Optical Unit Assembly
Item Description Part Number
Optical unit (exchange assembly), comes with foam part and CableFLM/FLF G1321-69002
1 Flash Lamp Board (FLL), includes trigger pack G1321-66512
2 Xenon flash lamp 2140-0600
3 Condenser Excitation 1000-1136
4Slit (EX) 2x4 G1321-08103
5Mirror 1000-1000
6 Excitation Monochromator assembly (complete) G1321-60003
7 Emission Monochromator assembly (complete) G1321-60004
8 Standard Flow Cell, 8 µl, 20 bar,
inlet i.d./length 0.17 mm/80 mm, outlet i.d./length 0.25 mm/80 mm
G1321-60005
Cuvette, 8 µl, 20 bar
inlet i.d./length 0.5 mm/80 mm, outlet i.d./length 0.5 mm/80 mm
G1321-60007
Screw for flow cell / cuvette G1321-22400
9Slit (EM) 2x8 G1321-08102
10 Photomuliplier tube assembly (PMT), see also page 180 for additional information 1970-0201
11 Condenser Emission 1000-1124
12 Front-end Board (FLF), underneath the optical (exchange assembly) (requires firmware
revision A.04.06 or above)
G1321-69531
12a Reference Diode Board (FLR) G1321-66533
12b Diffuser plate (in front of the reference diode board FLR) 1000-1121
13 Cutoff Filter 295 nm, for other type see page 215 5062-8530
14 Carbon filter mat 01046-42701
15 Cable FLM - FLF board (comes with optical unit) G1321-61600
