Agilent Technologies 1100 Series Reference Manual

Repairing the Fluorescence Detector 5
1100 Series FD Reference Manual 199
Replacing the Interface Board
To replace the interface board unscrew the two screws, remove the board,
slide in the new interface board and fix it with the board’s screws.
When required For all repairs inside the detector or for installation of the board
Part required Interface board (BCD) G1351-68701 with external contacts and BCD outputs
Interface board (LAN) see “LAN Board" on page 284
Tools re quired None
Figure 60 Location of the Interface Board
Interface board
