Agilent Technologies 1100 Series Reference Manual

16 1100 Series FD Reference Manual
1 Installing the Fluorescence Detector
Physical Specifications
Tabl e 1 Physical Specifications
Type Specification Comments
Weight 11.5kg (26lbs)
Dimensions
(width×depth×height)
345 × 435 × 140 mm
(13.5 × 17 × 5.5 inches)
Line voltage 100 – 120 or 220 – 240 VAC,
± 10 % Wide-ranging capability
Line frequency 50 or 60 Hz ± 5%
Power consumption 180 VA / 70 W / 239 BTU Maximum
Ambient operating temperature 0 – 40 ∞C (32 – 104 ∞F)
Ambient non-operating temperature -40 – 70 ∞C (-4 – 158 ∞F)
Humidity < 95%, at 25 – 40 ∞C (77 – 104 ∞F) Non-condensing
Operating altitude Up to 2000 m (6500 ft)
Non-operating altitude Up to 4600 m (14950 ft) For storing the detector
Safety standards: IEC, CSA, UL, EN Installation category II, pollution degree 2
