Repairing the Fluorescence Detector 5
1100 Series FD Reference Manual 133
Overview of the Repairing of the Fluorescence Detector
Figure 55 shows the main assemblies and their locations.
Figure 55 Main Assemblies
Flow cell,
see page 135
Leak handling system, see page 141
Leak sensor, see page 165
Interface board,
see page 199
Excitation
Monochromator,
see page 147
FLM Board,
see page 159
Photomultiplier Tube
see page 180
Fan,
see page 163
Power supply,
see page 190
Emission
Monochromator, see
page 147
Flash lamp,
see page 147
Flash lamp supply,
see page 183
Optical unit,
see page 178
condenser #1,
see page 180
Mirror,
see page 172
condenser #2
see page 180
