210 1100 Series FD Reference Manual
6 Identifying Parts and Materials
Plastic Parts
Tabl e 29 Plastics Parts
Item Description Part Number
1 Front cover 5062-8582
2 Plastics, includes base, sides and top 5062-8565
3 Name plate Agilent 1100 Series 5042-1381
4 Name plate Serial Number (w/o serial number) 5042-1314
NOTE
For correct assembling of the top and sides, see “Assembling the Main Cover" on page 198.
Figure 66 Plastic Parts
2
3
1
4
