Identifying Parts and Materials 6
1100 Series FD Reference Manual 203
Tabl e 24 Main Assemblies
Item Description Part Number
1 Detector main board FLM (exchange assembly) G1321-69500
Hexagonal nut for GPIB connector 0380-0643
Hexagonal nut for RS-232C connector 1251-7788
Nut for analog connector 2940-0256
Washer for analog connector 2190-0699
Cable CAN to Agilent 1100 Series modules (0.5 m), see page 233 5181-1516
2 Power supply for power and status light parts, see page 212 0950-2528
3 Interface board BCD (BCD/external contacts), optional G1351-68701
3 Interface board MIO (LAN), optional, see page 284
Fuse for BCD board, 250 mA (total of 4 are on the board) 2110-0004
4 Fan assembly 3160-1017
5 Optical unit (exchange assembly), for additional optical unit parts, see page 204 G1321-69002
6 Xenon flash lamp 2140-0600
7Mirror 1000-1000
8 Excitation Monochromator assembly (complete) G1321-60003
9 Emission Monochromator assembly (complete) G1321-60004
10 Photomuliplier tube assembly (PMT), see also page 180 for other types 1970-0201
11 Condenser EM, same as EX 1000-1124
12 Standard flow cell, 8 µl, 20 bar, see also page 204 for cell screws G1321-60005
13 Leak sensor assembly and Leak handling parts, see page 213 5061-3356
14 Cable FLM - FLF board (comes with optical unit) G1321-61600
Front cover and plastic parts (housing), see page 210
Sheet metal parts, see page 209
Foam parts, see page 211
