Identifying Parts and Materials 6
1100 Series FD Reference Manual 205
Foam Optics G1321-40103
16 Cable chassis G1321-61602
17 Screw M5 x 25 mm, for chassis cable 0515-2574
Screw 2.5 mm hex, for monochromator, lamp pad, condenser #1, slits, etc. 0515-1052
Screw M4 x 25 mm hex, for lamp housing 0515-2548
Screw M4 x 8 mm, for FLF board 0515-2549
Tabl e 25 Optical Unit Assembly (continued)
Item Description Part Number
