206 1100 Series FD Reference Manual
6 Identifying Parts and Materials
Figure 62 Optical Unit Parts
6 - Excitation
Monochromator
10 - Photomuliplier
7 - Emission
Monochromator
11 - Condenser EM
2 - Xenon Flash
Lamp, below pad
3 - Condenser EX
1 - FLL Board /
Trigger Pack
5 - Mirror
8 - Flow Cell
9 - Slit (EM/PMT)
4 - Slit (EX)
12 - FLF Board
(underneath)
12a Reference diode
FLR
9 - Slit (EM/PMT)
16 - Cable chassis
17 - Screw chassis
13 - Cutoff Filter
14 - Carbon filter mat
15 - Cable FLM/FLF
12b Diffuser plate
