Agilent Technologies 1100 Series Reference Manual

Repairing the Fluorescence Detector 5
1100 Series FD Reference Manual 145
2
Install the ESD strap. Move the power lock across the
power inlet and lift the clips on the rear of the cover.
3 If installed, unscrew and remove the interface board.
Place the board on the ESD kit.
4 Lift the cover up and slide it towards the rear. 5 Unscrew the screws at the rear of the top plate. Slide the
plate towards the front and remove it.
Warning:
Do not connect a power plug to the detector module after removing the top covers.
