Lesson 2 – Waveform Digitizer Setup with the Analog Setup Tool

180

How to Choose Your Favorite Editor

A sequencer program consists of a series of sequencer commands

which can be edited. You may wish to choose your favorite editor

to be started from the Analog Setup Tool. This can be done with

the C

ONFIG function.

Choosing a Custom Editor

Default Chapter3
