Lesson 1 – Analog Modules
69
Each output pin belongs to one AWG core only, and is not shared
by the other core.
In addition to the output routes, the DC routes and loop back
routes are available in the WGE. All routing is switched by the
output multiplexer.
For other components in the AWG (output amplifier, attenuator,
filter, DAC, timing generator, sequencer, waveform memory, and
SYNC_DATA pin), see the description in “High Resolution / High
Speed / 500M AWG” on page 66.
Mode Possible Pin Combinations of Output Routes (WGE)
Single-ended 8 outputs (4 outputs simultaneously):
(A+ or B+), (A- or B-), (C+ or D+), and/or (C- or D-)
Differential 4 outputs (2 outputs simultaneously):
(A+&A- pair or B+&B- pair) and/or (C+&C- pair or D+&D- pair)
Mix of single-ended and
differential
Single-ended mode in one AWG core, and differential mode in
the other AWG core.
