S331L UG PN: 10580-00321 Rev. M 4-3
Classic Mode Operation 4-1 Introduction
Descriptions of the main menus and associated submenus that are
common between the Classic and Advanced measurement modes are
provided in Chapter 3 in Figure 3-40 through Figure 3-54.
Table 4-1. Menu Differences Between Classic Mode and Advanced
Mode
Classic Mode
Advanced S331L Cable and Antenna
Mode
Mode Menu “Measurement Menu” on page 3-52
Freq - SWR “VSWR” on page 3-52
Freq - Return Loss “Return Loss” on page 3-52
Freq - Cable Loss (one
port)
“Cable Loss” on page 3-52
DTF - SWR “DTF VSWR” on page 3-52
DTF - Return Loss “DTF Return Loss” on page 3-52
— “Smith Chart” on page 3-53
— “1-Port Phase” on page 3-53
Freq/Dist Menu “Freq/Dist Menu” on page 3-54
F1 “Start Frequency (F1)” on page 3-54
F2 “Stop Frequency (F2)” on page 3-54
D1 “Start Distance (D1)” on page 3-54
D2 “Stop Distance (D2)” on page 3-54
More “DTF Setup” on page 3-55
Meas/Disp Menu
Refer to “Sweep Menu” on page 3-64 and
“Trace Menu” on page 3-65
Marker Menu
“Marker Menu” on page 4-6 “Marker Menu” on page 3-60
Limit Menu
“Limit Menu” on page 4-8 “Limit Menu” on page 3-62
Note
Also refer to Chapter 3 for descriptions of other menus not
specifically mentioned in Table 4-1.
