Anritsu Site Master S331L User Manual

3-46 PN: 10580-00321 Rev. M S331L UG
3-7 Trace Cable and Antenna Measurements
Trace Math Example
The example below illustrates how the trace math features can be used
to compare the phase of two cables.
1. Complete the steps described in “Trace Overlay” on page 3-45.
2. Press Trace Math and select Trace - Mem , Trace + Mem, or
(Trc + Mem) / 2 (Figure 3-37).
Figure 3-37. Trace Memory Used to Compare the Phase of Two Cables
Example A. Sample Traces
Example B. Trace - Memory
Example C. Trace + Memory
Memory Trace
(Purple)
Live Trace
(Yellow)
