Sheet #647u – Permanent regulator
Version 1.04a User guide ATEQ 6th series Page 1/1
PERMANENT REGULATOR
When an electronic regulator is used with a test part with a small volume and requiring a fast
cycle time this function should be activated. The instrument will regulate the air pressure to the
set fill value for the entire test sequence including the time between tests.
1. PROCEDURE
From the "CONFIGURATION" menu, select
the "PNEUMATIC" menu and then press the
button.
/#+0%10(+)74#6+10
LANGUAGE : English
Ź PNEUMATIC
AUTOMATISM
SECURITY
MISCELLANEOUS
Then by using the arrows,
select the "PERM REG." menu and validate
with the
key.
/#+0%10(+
20'7/#6+
ELEC. REG: 10000 hPa
REGUL. CTRL. : AUTO
Ź PERM. REG. : No
PIEZO AUTO AZ : No
AZ SHORT : No
Press UNIT : bar
BLOW MODE : No
DUMP LEVEL : No
By using the arrows, select
"Yes" and validate with the
key.
/#+0%10(+
20'7/#6+
ELEC. REG: 10000 hPa
REGUL. CTRL. : AUTO
Ź PERM. REG. : Yes
PIEZO AUTO AZ : No
AZ SHORT : No
Press UNIT : bar
BLOW MODE : No
DUMP LEVEL : No
