Sheet #617u – Stamping function
Version 1.04a User guide ATEQ 6th series Page 1/1
STAMPING FUNCTION
1. PRESENTATION
This option is used to activate a pneumatic output which marks the part (for example using a
pneumatic cylinder).
Parameters can be set for the conditions and duration of marking.
This function is available either with an external output and either by a pneumatic output (one of
the pneumatic outputs on the automatic connectors is used) and this option requires two
electrical outputs:
9 one internal for the pneumatic output cabling,
9 one external for the "customer" cabling.
The output is activated at the end of test time for the programmed hold time.
2. PROCEDURE
Activate the function or check if it checked.
Press the
key, the cursor slide to the
right hand.
2#4#/2T
(70%6+10
ŹSTAMPING : No
More functions…
By using the arrows, select
"Yes" and validate with the
key.
2#4#/2T(70%6+10
STAMPING : Yes Ż
More functions…
Adjust the stamping parameters.
DURATION = holding time.
Stamping conditions
:
ALL RESULTS = all conditions,
PASS = good part,
TEST FAIL = bad part on the test,
REF FAIL = bad part on the reference,
ALARM = alarm triggered,
P OUT OF LIMITS = pressure error.
2T
(70%656#/2+0
Ź DUTATION : 0.0 s
ALL RESULTS : No
PASS : Oui
T FAIL : No
R FAIL : No
ALARM : No
PRESSURE OUT : No
