Sheet #683u –Optional Accessories
Version 1.04a User guide ATEQ 6th series Page 6/6
6. REMOTE CONTROLS
The remote control allows remote control and selection of various settings for ATEQ
instruments. This remote control is connected to the instrument’s relay board.
6.1. RESET/START REMOTE
Télémécanique
TLC
6.2. FOUR-FUNCTION 128 PROGRAMS REMOTE CONTROL REMOTE CONTROL
This remote control has four functions which can be
used to control an instrument remotely.
The four functions on this remote control are as
follows:
9 Reset and start cycle.
9 Increase or decrease program numbers.
9 Display the selected program number.
9 Display the test result, green indicator light for
Pass, red indicator light for Fail or alarm.
Note: a program number can only be changed
(increase or decrease) when no test cycle is running.
TLC60
8 8 8
At the device powering up, as the "End of cycle" information is not on, the TLC60 remote control
displays alternatively its firmare version and the lights test.
6.3. CONNECTION DIAGRAM
F 6xx
TLC60
To Next Page
