Sheet #658u –Valve Service (Counters)
Version 1.04a User guide ATEQ 6th series Page 1/1
VALVE SERVICE (COUNTERS)
This menu gives the approximate state of the internal valves with the counters indications.
1. PROCEDURE
From the "SERVICE" menu, select the
"VALVE COUNTER" menu by using the
arrows.
/#+05'48+%'
RESET PARA : No
CAN STATUS
I/O STATE
Ź VALVE COUNTER
DEVICE INFOS
SERVICE CYCLE : No
Two valve counters are displayed: Total and
Partial.
Partial: total number of cycles the valve has
performed since the last counter reset. This
counter can be reset by the user
Total: total number of cycles the valve has
performed. This counter is managed by ATEQ
Company; it is reset once a complete service
is carried out on the valves.
/#+05'48+8#.8'%1
Ź Partial : 181
Total : 181
Partial Reset
Partial Reset: to reset the partial counter.
/#+05'48+8#.8'%1
Partial : 0
Total : 181
Ź Partial Reset
To Next Page
