Sheet # 680f – Leak programs parameters
Version 1.04a User guide ATEQ 6th series Page 1/9
LEAK PROGRAM PARAMETERS
This sheet is for the leak test parameters only, for the others tests types, see the sheet about
the type.
1. ADJUST PROCEDURE
The procedure to set test parameters is identical for each timer (fill, stabilization, test...)
example with coupling time A:
The instrument can handle up to 128 different test programs.
To access to the parameters menu, from the
cycle menu, press the
or
keys.
Pr 001
LEAK TEST
Then select the
menu
Select a program by using the
keys.
2#4#/'6'45
Ź Copy-Paste
Pr:01 -----------------
Pr:02 -----------------
Pr:03 -----------------
Pr:04 -----------------
Pr:05 -----------------
Pr:06 -----------------
Pr:07 -----------------
If the program is empty, the device will ask the
test type to apply, select it with the
keys.
Note: This menu may change following the
device options.
2#4#/6;2'
Ź LEAK TEST
BLOCKAGE
DESENSITIZED TEST
OPERATOR
