ATEQ PRIMUS F Series - Sealed Components Special Cycle Learning

Sheet #613u – Sealed components
Version 1.04a User guide ATEQ 6th series Page 7/8
4. SEALED COMPONENT SPECIAL CYCLE LEARNING
For sealed components, learning cycles for Pass and Fail must be performed so that the
instrument calculates the parameters.
As the learning cycles have not been carried out, the device cannot run test cycles.
¾Sealed PASS Part Learn: This learning cycle calculates and identifies the value of the pass
part together with the maximum and minimum limits (+/- 5 % modifiable). This cycle is
compulsory for sealed component mode.
¾Sealed FAIL Part Learn: this cycle allows learning the pressure parameters for a fail part
by taking an average between the value of a pass part and that of a fail part. This cycle is
not compulsory.
From the main menu, enter the special cycle
menu.
In the special cycle menu, select
"
Sd PASS Prt Learn".
52'%;%.'
none
Regul. adjust
Infinite fill
Piezo auto zero
Ź Sd PASS Prt Learn
Sd FAIL Prt Learn
Remind: it's important to have a pass part
plugged.
The cycle screen is displayed confirming the
special cycle selection. Ensure that a pass
part is inside the chamber and run the special
cycle by pressing the START
key.
52'%;%.'
Sd Part
Pr 001
LEAK TEST
The learning cycle is running with the following
steps:
VOLUME FILL, VOLUME TRANSFERT and
TEST.

REMPLISSAGE V
000
Pr 01
Pa
1.4 s
The final result must be Pass (
OK).

100.0
mbar
OK
050
Pa
000
Pr 01
Pa
0.0 s
