Sheet #655u –External dump option
Version 1.04a User guide ATEQ 6th series Page 1/1
EXTERNAL DUMP (OPTIONAL)
The external dump has the advantage to prevent impurities, liquid or any other particles to be
vented through the instrument’s internal valve and therefore protects it.
This option activates the pilot of an external dump valve (such as ATEQ leak tight 3/2 valve).
This option requires an external electrical or pneumatic pilot (contact ATEQ to add
the option). If the instrument is equipped with this option, one of the internal and
external valve codes or one of the auto connector will be occupied.
1. PROCEDURE
In the functions menu, validate with "Yes" the
"Ext. Dump" function.
/#+0%10(+
20'7/#6+
REGUL. CTRL. : AUTO
PERM. REG. : No
PIEZO AUTO AZ : No
AZ SHORT : No
Press UNIT : bar
BLOW MODE : No
DUMP LEVEL : No
Ź EXT. DUMP : Yes
The menu for the configuration of the external
dump mode is displayed, normally CLOSED
or normally OPEN and the running mode
TIME or CONTINUOUS.
(70%6
':6'0
':6&7/
Ź EXT. DUMP : CLOSED
MODE : TEMPS
Check the function.
Press the
key the cursor slide to the
right hand.
2T
(70%6+105
Ź EXT. DUMP : No
More functions…
By using the arrows, select
"Yes" and validate with the
key. The
external dump can perform.
2T(70%6+105
Ź EXT. DUMP : Yes Ż
More functions…
