Sheet #610u – End of cycle
Version 1.04a User guide ATEQ 6th series Page 1/7
END OF CYCLE
This function enables the choosing of one of the different end of cycle depending on the
configuration of the instrument (connection to a PLC…).
1. RELAY SEQUENCING RELATED TO DIFFERENT END OF CYCLE
In order to interface the ATEQ with its environment (PLC, PC …), the following timing charts
supply the details of the sequencing of the electrical outputs (relay board on the J3 connector)
and pneumatic outputs (automatic connectors), depending on the commands entered on the
front panel or through the J3 connector (START, RESET).
Legend
A
Coupling time A
B
Coupling time B
P - F
Pre-fill time
P - D
Pre-dump time
F
Fill time
S
Stabilization time
#
Unspecified time occurring between the programmed test time and the
pressing of the reset
key.
T
Test time
D
Dump time
START
Press the
key on the front panel or short pins 2-3 on the relay
board connector.
RESET
Press the
key on the front panel or short pins 1-2 on the on
the relay board connector.
Automatic
Connector
Active (high level): the pneumatic output is active (air output).
Inactive (low level): the pneumatic output is inactive (no air output).
PASS or
FAIL
Fail part or Pass part relay on the on the relay board connector
EoC
End of cycle relay on the relay board connector
t mini
Minimum time to accept an entry 50 ms on connector on the relay
board.
Actual times are not those displayed but those on the print-out.
