ATEQ PRIMUS F Series User Manual

Sheet #601u – Functions management
Version 1.04a User guide ATEQ 6th series Page 17/26
1.3.5. Available functions for Burst test
FUNCTIONS
Name
Burst = OK > No / Yes
Pr: Sequence > Next Prog. > XX+
v Inter-Cyc > 0,0 S
v All Results > No / Yes
v Pass > No / Yes
v T Fail > No / Yes
v R Fail > No / Yes
v Alarm > No / Yes
v Pressure Out > No / Yes
v Reworkable > No / Yes
v Test Check > No / Yes
v
Automatic
Connectors
> Coupling A > 0 > 650 s
v Coupling B > 0 > 650 s
v v
Fill Mode Fill regulator > 1
v 2
v
External dump > Closed
One choice for all
the programs
v Open
One choice for all
the programs
Mode > Continuous
Closed only
Time
v
Valve Codes Ext. 1 Yes
v Delay Ext 0.0 S
v Time Ext1 0.0 S
Same time for all
the programs
v Ext. 2
v Ext. 3
v Ext. 4
v Ext. 5
v Ext. 6
v Int. 1
v Int. 2
v
24V outputs > Aux 1 > No / Yes
v Delay Aux > 0 > 650 s
v Time Aux1 > 0 > 650 s
v Aux 2
v Aux 3
v Aux 4
v
End Of Cycle > Auto Reset
