Sheet #639u – Buzzer
Version 1.04a User guide ATEQ 6th series Page 1/1
BUZZER
This menu is used to manage when the buzzer will sound.
1. PROCEDURE
Activate the function or check if it checked.
Press the
key, the cursor slide to the
right hand.
2#4#/2T
(70%6+10
Ź BUZZER : No
More functions…
By using the arrows, select
"Yes" and validate with the key.
2#4#/2T
(70%6+10
BUZZER : Yes Ż
More functions…
Then by using the keys
select the buzzer trigger mode:
PB = OK : at each pass, the buzzer will
sound.
FAIL = Fail part, at each fail part, the buzzer
will sound.
ALA = Alarm : if an alarm is triggered, the
buzzer will sound to warn the user.
FDC = Fin de cycle : at each time the device
ends its cycle, the buzzer will sound.
Select "Yes" and then validate with the
key.
Note: Several options can be checked.
#/2T
(10%6
$7<<'
Ź PB : No
FAIL : No
ALA : No
EOC : No
Uncheck all options if you do not want the buzzer to sound.
