Sheet #681u – Test cycle management
Version 1.04a User guide ATEQ 6th series Page 1/2
TEST CYCLE MANAGEMENT
1. STARTING A CYCLE
1.1. TEST PRESSURE ADJUSTMENT
When instrument is fitted with an electronic regulator, the test pressure value is that shown
since this is the fill target. No special cycle is required.
When instrument is fitted with a mechanic regulator, the test pressure has to be adjusted by
running the special cycle "Regulator adjust".
Reminder: the regulator input pressure must be at least 10% greater than the value of full scale
on the electronic regulator + 100 kPa (+ 1 bar).
1.2. R
UN A MEASUREMENT CYCLE
Press the START to run the measurement
cycle.
Pr 001
LEAK TEST
The following steps are displayed on the
screen :
COUPLING,
FILL,
STABILIZATION,
TEST,
DUMP.
100.0
mbar
TEST
050
Pa
15
Pr 01
Pa
1.4 s
At the end of the cycle the result is displayed.
Result with a Pass part:
600.0
mbar
OK
50
Pa
27
Pr1
Pa
READY
