ATEQ PRIMUS F Series - Auto Zero Short

Sheet #649u – Auto zero short
Version 1.04a User guide ATEQ 6th series Page 1/2
AUTO ZERO SHORT
Each time the instrument performs a pressure sensor (piezzo) auto zero, it also re-linearizes the
electronic regulator. The linearization process might be too long for some application. Auto-zero
short skips the linearization process and zeros the pressure sensor only.
Only the automatics auto-zeros take in account the programmed times.
The auto-zeros perform on demand have the 0.5 seconds time.
1. PROCEDURE
From the "CONFIGURATION" menu, select
the "PNEUMATIC" menu and then press the
button.
/#+0%10(+)74#6+10
LANGUAGE : English
Ź PNEUMATIC
AUTOMATISM
SECURITY
MISCELLANEOUS
Then by using the arrows,
select the "PIEZO AUTO AZ" menu and
validate with the
key.
/#+0%10(+

20'7/#6+
ELEC. REG: 10000 hPa
REGUL. CTRL. : AUTO
PERM. REG. : No
PIEZO AUTO AZ : No
Ź AZ SHORT : No
Press UNIT : bar
BLOW MODE : No
DUMP LEVEL : No
By using the arrows, select
"Yes" and validate with the
key.
/#+0%10(+

20'7/#6+
ELEC. REG: 10000 hPa
REGUL. CTRL. : AUTO
PERM. REG. : No
PIEZO AUTO AZ : No
AZ SHORT : Yes Ż
Press UNIT : bar
BLOW MODE : No
DUMP LEVEL : No
Then configure the AZ short time.
/#+0%10(+

20'7/

#<
Ź AZ SHORT : 0.2 s
