Sheet #620u – Peak hold
Version 1.04a User guide ATEQ 6th series Page 1/1
PEAK HOLD
1. PRINCIPLE
The peak hold mode is used to measure a part dynamically. The instrument measures the leak,
which can change at a given moment during the test. The instrument stores the greatest
pressure drop ('P/'t) and then displays it at the end of the test.
This function is important in circumstances where the test part changes during the test cycle.
The system checks the part for leaks in ǻP/ǻt throughout the change and the leak is measured
continuously. At the end of the test cycle, the instrument has stored the maximum
instantaneous leak (the greatest leak) recorded during the test and displays the result.
LEAK ǻP/ǻt
MAXIMAL
VALUE
MEASURED
0
TIME
Peak measurement mode only works in
'
P/
'
t and excludes the use of ATR mode.
2. CONFIGURATION
Activate the function or check if it checked.
Press the
key, the cursor slide to the
right hand.
2#4#/2T
(70%6+10
ŹPEAK HOLD : No
More functions…
By using the arrows, select
"Yes" and validate with the
key.
2#4#/2T(70%6+10
PEAK HOLD : Yes Ż
More functions…
