Sheet # 688u – "Smart Key"
Version 1.04a User guide ATEQ 6th series Page 1/1
"SMART KEY"
The "Smart Key" button is a programmable key, it can be programmed following the user
preferences; this can have a direct access to the selected function.
1. PROCEDURE
From the "CONFIGURATION" menu, select
the "MISCELLANEOUS" menu and then
press the
button
/#+0%10(+)74#6+10
LANGUAGE : English
PNEUMATIC
AUTOMATISM
SECURITY
Ź MISCELLANEOUS
By using the arrows, select
the "SMART KEY" menu and validate with the
key.
/'07%10(+&+8'45
SMART KEY: CYCLE SPE Ż
By using the arrows, select
the function to assign to the key, and then
validate with the
key.
Special cycle menu: to access to the menu
of special cycle selection.
Special cycle: to run the special cycle
selected in the list of the available ones.
Parameters: to access directly to the program
parameters menu.
Program defined: to access directly to the
selected program parameters.
Run program: to access directly to the
current program parameters (run program).
Last results: to access directly to the test
results menu.
Password: to be allow to type the password
for parameters access.
/#+0%10(+/+5%'5/
Ź SPECIAL MENU CYCLE
SPE CYCLE
PARAMETERS
PROG. DEFINED
RUN PROG.
LAST RESULTS
PASSWORD
