ATEQ PRIMUS F Series User Manual

Sheet #601u – Functions management
Version 1.04a User guide ATEQ 6th series Page 16/26
1.3.4. Available functions for operator test
FUNCTIONS
Name
Pr: Sequence Next Prog. > XX+
v Inter-Cyc > 0,0 S
v All Results > No / Yes
v Pass > No / Yes
v Fail > No / Yes
v
Automatic
Connectors
> Coupling A > 0 > 650 s
v Coupling B > 0 > 650 s
v
Valve Codes Ext. 1 Yes
v Delay Ext 0.0 S
v Time Ext1 0.0 S
Same time for all
the programs
v Ext. 2
v Ext. 3
v Ext. 4
v Ext. 5
v Ext. 6
v Int. 1
v Int. 2
v
24V outputs > Aux 1 > No / Yes
v Delay Aux > 0 > 650 s
v Time Aux1 > 0 > 650 s
v Aux 2
v Aux 3
v Aux 4
v
Stamping Duration
v All Results
v Pass
v Fail
v Alarm
v Pressure Out
v
Buzzer > Pass part > No / Yes
10 beeps
v Fail part > No / Yes
Long beep
v Alarm > No / Yes
Long beep
v End of cycle > No / Yes
10 beeps
