Sheet #687u – Displaying results in flow unit
Version 1.04a User guide ATEQ 6th series Page 2/3
Change leak unit by a flow unit: example
cm3/min or similar.
2#4#/2T
STAB TIME : 4.0 s
TEST TIME : 2.0 s
DUMP TIME : 0.8 s
Press. UNIT: mbar
Max FILL : 750.0
Min FILL : 450.0
Set FILL : 600.0
Ź LeakUnit : cm3/mn
Some more parameters are displayed:
“Volume UNIT” and “VOLUME”.
Select “Volume UNIT”.
2#4#/2T
LeakUnit : cm3/mn
Pa DISPLAY : No
REJECT CALC : Pa
Ź Volume UNIT : cm3
VOLUME : 15.00
Test FAIL : 0.450
Ref. FAIL : 0.000
FUNCTIONS
Choose the volume unit among: cm
3
, mm
3
, ml
or l.
2#4#/2T
LeakUnit : cm3/mn
Pa DISPLAY : No
REJECT CALC : Pa
Ź Volume UNIT : cm3
VOLUME : 15.00
Test FAIL : 0.450
Ref. FAIL : 0.000
FUNCTIONS
Select the “VOLUME” parameter.
Enter the estimated value of the volume of the
part to be tested, in the unit previously
selected (cm3 in this example). The volume is
the volume internal of the instrument + the
volume of the tubing + volume of the part. The
volume will be readjusted later.
2#4#/2T
LeakUnit : cm3/mn
Pa DISPLAY : No
REJECT CALC : Pa
Volume UNIT : cm3
Ź VOLUME : 15.00
Test FAIL : 0.450
Ref. FAIL : 0.000
FUNCTIONS
Select the “Test FAIL”. Parameter, Enter the
reject level for the leak test in the unit
previously selected.
2#4#/2T
LeakUnit : cm3/mn
Pa DISPLAY : No
REJECT CALC : Pa
Volume UNIT : cm3
VOLUME : 15.00
Ź Test FAIL : 0.450
Ref. FAIL : 0.000
FUNCTIONS
1) Start a first cycle with a known pass part
and take note of the result value. Wait a
minute.
600.0
mbar
OK
0.450
cm3/mn
0.186
Pr1
cm3/mn
READY
