Sheet #696u – USB (Automatism)
Version 1.04a User guide ATEQ 6th series Page 3/5
Examples of results frames.
Pass part frame: <01>:
<01>:30/05/2012 16:52:01
<01>: 487.8 mbar:(OK): 029 Pa
Fail part frame: <01>:
<01>:30/05/2012 16:53:36
<01>: 493.9 mbar:(DT): 114 Pa
Alarm frame: <02>:
<02>:30/05/2012 16:55:24
<02>: 486.4 mbar:(AL): >> F.S. TEST
This frame is of the same type as the print parameters frame except that the different character
strings follow each other and are separated by a punctuation mark which enables the various
boxes to be entered automatically in Microsoft Excel.
This frame is operated by connecting a computer to the instrument's RS 232 link.
Columns detail:
1) Personalization
2) Program Number
3) Test result message.
4) Numerical Test Value.
5) Test unit.
6) Numerical pressure value.
7) Pressure Unit.
8) Alarm Message.
8') Bar Code (option: depends of the
device version).
9) Date.
10) Time.
1.1.1. Export mode
Export: This function can be used to create
and send a special results frame which can be
processed by a PC using Microsoft Excel.
The characters and codes are from the ASCII
table codes.
+0%10(+#761/75$
Print Frame
Sending Cond.
Ź Export : No
Print parameters
Exports examples: (the following example is from a F5 version v1.18p device).
The character "Æ" represents a tab HT (09h).
The character "" represents a space (20h).
The character "" represents a carriage return CR (0Dh).
