Sheet #613u – Sealed components
Version 1.04a User guide ATEQ 6th series Page 3/8
The instrument allows for variations in input pressure. This is why the maximum
and minimum parameters vary for each cycle.
At the end of a learning cycle (fill of the volume, volume transfer, dump) the Pass part and
End of Cycle outputs are activated. If the volume is greater (large leak), the Fail Part and
End of Cycle outputs are activated. If the volume is reduced (problem with the fixture) the
Alarm and End of Cycle outputs are activated.
Learning cycles for pass parts and parts with a large leak are accessed through the main menu
under special cycles.
Test cycles cannot be carried out unless learning cycles have previously been carried out.
