Atmel AVR XMEGA AU series User Manual

396
8331B–AVR–03/12
Atmel AVR XMEGA AU
29.10.12 CH1GAINCAL – Gain Calibration Register
• Bit 7:0 – CH0GAINCAL[7:0]: Gain Calibration value
These bits are used to compensate for the gain error in DAC channel 1. See ”Calibration” on
page 388 for details.
29.10.13 CH0OFFSETCAL – Offset Calibration Register
• Bit 7:0 – CH1OFFSETCAL[7:0]: Offset Calibration value
These bits are used to compensate for the offset error in DAC channel 1. See ”Calibration” on
page 388 for details.
Bit 76543210
+0x0A CH1GAINCAL[7:0] CH1GAINCAL
Read/Write R R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
Bit 76543210
+0x0B CH1OFFSETCAL[7:0] CH1OFFSETCAL
Read/Write R R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
