Automation Direct DURApulse GS4 User Manual

Chapter 4: AC Drive Parameters
Page 4–7
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
GS4 Parameters Summary – Digital Parameters (P3.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P3.03
Multi-Function Input (DI1)
0: No function
1: Multi-Speed/PID Multi-Setpoint bit 1
2: Multi-Speed/PID Multi-Setpoint bit 2
3: Multi-Speed/PID Multi-Setpoint bit 3
4: Multi-Speed bit 4
5: Reset
6: JOG
7: Accel/Decel speed inhibit (Speed Hold)
8: 1st~4th Accel/Decel time selection, bit 0
9: 1st~4th Accel/Decel time selection, bit 1
10: Emergency Stop EF Input by P3�56 (EF
error)
11: Base Block Input
12: reserved
13: Disable Auto Accel/Decel Time
14: Switch between drive settings 1 and 2
15: Operation speed command from AI1
16: Operation speed command from AI2
17: Operation speed command from AI3
18: Forced Ramp Stop by P3�56 (no error)
19: Digital Freq Up Command
20: Digital Freq Down Command
21: PID function Disable
22: Clear counter
23: Increment counter value (DI6 only)
24: FWD JOG
25: REV JOG
26: Emergency Stop EF1 (Coast stop)(EF1 error)
27: Signal Confirmation for Y-connection
28: Signal Confirmation for Delta connection
29: Disable EEPROM Write
30: Forced Coast Stop
31: Hand Contact for HOA Control
32: Auto Contact for HOA Control
33: LOCAL/REMOTE Selection
34: Drive Enable
35: Decel Energy Backup (DEB) Enable
36: PLC Mode select bit0
37: PLC Mode select bit1
38: Output MCR Auxiliary Confirmation
39: reserved
40: Fire mode and force drive run
41: Fire mode and maintain operation
42: Disable all motors
43: Disable Motor #1
44: Disable Motor #2
45: Disable Motor #3
46: Disable Motor #4
47: Disable Motor #5
48: Disable Motor #6
49: Disable Motor #7
50: Disable Motor #8
R/W 0303 40772 1
P3.04
Multi-Function Input (DI2) R/W 0304 40773 2
P3.05
Multi-Function Input (DI3) R/W 0305 40774 3
P3.06
Multi-Function Input (DI4) R/W 0306 40775 4
P3.07
Multi-Function Input (DI5) R/W 0307 40776 0
P3.08
Multi-Function Input (DI6) R/W 0308 40777 0
P3.09
Multi-Function Input (DI7) R/W 0309 40778 0
P3.10
Multi-Function Input (DI8) R/W 030A 40779 0
P3.11
Multi-Function Input
(option card DI10 or PLC
X12)
R/W 030B 40780 0
P3.12
Multi-Function Input
(option card DI11 or PLC
X13)
R/W 030C 40781 0
P3.13
Multi-Function Input
(option card DI12 or PLC
X14)
R/W 030D 40782 0
P3.14
Multi-Function Input
(option card DI13 or PLC
X15)
R/W 030E 40783 0
P3.15
Multi-Function Input
(option card DI14 or PLC
X16)
R/W 030F 40784 0
P3.16
Multi-Function Input
(option card DI15 or PLC
X17)
R/W 0310 40785 0
(table continued next page)
