Automation Direct DURApulse GS4 User Manual

Chapter 4: AC Drive Parameters
Page 4–9
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
GS4 Parameters Summary – Digital Parameters (P3.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P3.39
Increase/Decrease Speed
Mode
0�000: Following Accel/Decel Time
0�001~1�000 Hz/ms: Following Constant Speed
♦R/W 0327 40808 0
P3.40
DI6 Counter Debounce
Filter
0�00~30�00 sec ♦R/W 0328 40809 0�02
P3.41
Digital Input Response
Time
0~30�000 sec ♦R/W 0329 40810 0�005
P3.42
Multi-Function Input
Contact Selection (0=N�O�
/ 1=N�C�)
0~65535
0~65535
R/W 032A 40811 0
P3.43
Multi-Function Output
Contact Selection (0=N�O�
/ 1=N�C�)
♦R/W 032B 40812 0
P3.44
Final Counter Value 0~65500 ♦R/W 032C 40813 0
P3.45
Mid-point Counter Value 0~65500 ♦R/W 032D 40814 0
P3.46
Digital Input Active Status 0~65535 Read 032E 40815 0
P3.47
Digital Output Active
Status
0~65535 Read 032F 40816 0
P3.48
PLC – Digital Input Mask 0~65535 Read 0330 40817 0
P3.49
PLC – Digital Output Mask 0~65535 Read 0331 40818 0
P3.50
Increase/Decrease Speed
Command Record
0~600�00 Read 0332 40819 60
P3.51
Brake Delay Time 0�000~65�000 sec R/W 0333 40820 0
P3.52
Desired Current 0~150% of GS4 VT current rating ♦R/W 0334 40821 0
P3.53
Output Frequency
Threshold for Multi-
Function Output Terminals
0�00~600�00 Hz ♦R/W 0335 40822 0
P3.54
reserved n/a n/a 0336 40823 n/a
P3.55
reserved n/a n/a 0337 40824 n/a
P3.56
Emergency Stop (EF) &
Force Stop Selection
0: Coast Stop
1: Deceleration Time 1
2: Deceleration Time 2
3: Deceleration Time 3
4: Deceleration Time 4
5: System Deceleration
6: Automatic Deceleration
R/W 0338 40825 0
P3.57
AUTO to HAND Switching
Behavior
0~Fh
bit 0: Sleep function control bit
bit 1: Parameter units displayed on keypad
bit 2: PID control bit
bit 3: Source of frequency control bit
♦R/W 0339 40826 0
P3.58
Local/Remote Switch Mode
0: HAND/OFF/AUTO control
1: Always Stop When Switching
2: Follow Remote Mode
3: Follow Local Mode
4: Follow Local and Remote Mode
R/W 033A 40827 4
