Automation Direct DURApulse GS4 User Manual

Page 4–16
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
GS4 Parameters Summary – Protection Parameters (P6.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P6.13
Auto Adjustable Accel/
Decel
0: Linear Accel/Decel
1: Auto Accel, Linear Decel
2: Linear Accel, Auto Decel
3: Auto Accel, Auto Decel
4: Auto Accel/Decel Stall Prevention
(limited by P1�01~P1�08 and P1�13~P1�14)
♦R/W 060D 41550 0
P6.14
Over-Torque Detection
Mode (OT1)
0: Disable
1: Enable during at speed
2: Enable during at speed and Stop
3: Enable during OP
4: Enable during OP and Stop
♦R/W 060E 41551 0
P6.15
Over-Torque Detection
Level (OT1)
10~200% ♦R/W 060F 41552 120
P6.16
Over-Torque Detection
Time (OT1)
0�1~60�0 sec ♦R/W 0610 41553 0�1
P6.17
Over-Torque Detection
Mode (OT2)
0: Disable
1: Enable during at speed
2: Enable during at speed and Stop
3: Enable during OP
4: Enable during OP and Stop
♦R/W 0611 41554 0
P6.18
Over-Torque Detection
Level (OT2)
10~200% ♦R/W 0612 41555 120
P6.19
Over-Torque Detection
Time (OT2)
0�1~60�0 sec ♦R/W 0613 41556 0�1
P6.20
Over-Current Stall
Prevention Level During
Accel
0~160% (by P6�34 setup; VT: 0~130%; CT:
0~160%)
0: Disable
♦R/W 0614 41557
VT: 120
CT: 150
P6.21
Over-Current Stall
Prevention Level During
Operation
0~160% (by P6�34 setup; VT: 0~130%; CT:
0~160%)
0: Disable
♦R/W 0615 41558
VT: 120
CT: 150
P6.22
Maximum Allowable
Power Loss Time
0�0~20�0 sec ♦R/W 0616 41559 2�0
P6.23
Base-Block Time for
Speed Search
0�1~20�0 sec ♦R/W 0617 41560 0�5
P6.24
Maximum Speed Search
Current Level
20~200% ♦R/W 0618 41561 100
P6.25
Upper Limit of Output
Frequency
0�00~600�00 Hz ♦R/W 0619 41562 600�00
P6.26
Lower Limit of Output
Frequency
0�00~600�00 Hz ♦R/W 061A 41563 0�00
P6.27
Over-Voltage Stall
Prevention Level
230V: 300�0~450�0 VDC
460V: 600�0~900�0 VDC
♦R/W 061B 41564
390�0
780�0
P6.28
Dynamic Braking Voltage
Level
230V: 350�0~450�0 VDC
460V: 700�0~900�0 VDC
♦R/W 061C 41565
390�0
780�0
P6.29
Line Start Lockout
0: Enable start-up lockout
1: Disable start-up lockout
♦R/W 061D 41566 0
P6.30
Heat Sink OH Warning
Level
0�0~110�0 °C ♦R/W 061E 41567 105�0
P6.31
Cooling Fan Control
0: Always ON
1: Fan OFF 1 minute after Stop
2: Run fan ON/Stop fan OFF
3: Heat sink temperature
4: Always OFF
♦R/W 061F 41568 0
P6.32
PWM Fan Speed 0~100% R/W 0620 41569 60
(table continued next page)
