Page 4–18
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
GS4 Parameters Summary – Protection Parameters (P6.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P6.52
Low Current Level 0�0~100�0% R/W 0634 41589 0�0
P6.53
Low Current Detection
Time
0�00~360�00 sec R/W 0635 41590 0�00
P6.54
Low Current Action
0: Disable, no warning
1: Warn and coast to stop
2: Warn and ramp to stop by 2nd decel time
3: Warn and continue operation
R/W 0636 41591 0
P6.55
Fire Mode
0: Disable
1: Forward Operation
2: Reverse Operation
R/W 0637 41592 0
P6.56
Fire Mode Operation
Frequency
0�00~600�00 Hz R/W 0638 41593 60�00
P6.57
Fire Mode Enable Bypass
0: Disable Bypass
1: Enable Bypass
R/W 0639 41594 0
P6.58
Fire Mode Bypass Delay
Time
0�0~6550�0 sec R/W 063A 41595 0�0
P6.59
Fire Mode Auto Restart
Counter
0~10 R/W 063B 41596 0
P6.60
Fire Mode Auto Restart
Counter Reset Time
0�0~6000�0 sec R/W 063C 41597 60�0
P6.61
Decel Energy Backup
(DEB) Decel Selection
0: Disable
1: 1st Decel Time
2: 2nd Decel Time
3: 3rd Decel Time
4: 4th Decel Time
5: Current Decel Time
6: Auto Decel Time
♦R/W 063D 41598 0
P6.62
DEB Offset Level
230V models: 0�0~100�0 VDC
460V models: 0�0~200�0 VDC
R/W 063E 41599
40�0
80�0
P6.63
DEB Disable Voltage
Level
230V models: 0�0~200�0 VDC
460V models: 0�0~400�0 VDC
R/W 063F 41600
150�0
300�0
P6.64
DEB Delay Time 0�0~25�0 sec ♦R/W 0640 41601 0�0
P6.65
Dwell Time at Accel 0�00~600�00 sec ♦R/W 0641 41602 0
P6.66
Dwell Frequency at Accel 0�00~600�00 Hz ♦R/W 0642 41603 0
P6.67
Dwell Time at Decel 0�00~600�00 sec ♦R/W 0643 41604 0
P6.68
Dwell Frequency at Decel 0�00~600�00 Hz ♦R/W 0644 41605 0
P6.69
Input Phase Loss
Detection Time
0�00~600�00 sec R/W 0645 41606 0�20
P6.70
Input Phase Loss Ripple
Detection
230V models: 0�0~160�0 VDC
460V models: 0�0~320�0 VDC
R/W 0646 41607
30�0
60�0
P6.71
STO Alarm Latch
0: STO Alarm Latch
1: STO Alarm no Latch
♦R/W 0647 41608 0
To Next Page
