Chapter 4: AC Drive Parameters
Page 4–29
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
PuMP ParaMeters suMMary (P10.xx)
For detailed information about the P10.xx parameter group, please refer to page 4–193.
GS4 Parameters Summary – Pump Parameters (P10.xx)
Parameter Range
Run
1)
Read/
Write
Modbus
Address
Settings
Hex Dec Default
2)
User
1) ♦ in the Run-Read/Write column indicates that the parameter can be set during RUN mode.
R/W indicates “read/write.”
Read indicates “read-only.”
2) Parameters can be restored to their default values using P9.08.
P10.00
Circulative Control
0: no function
1: Time Circulation
2: Quantity Cycle
3: Quantity Control
4: Time Circulation + Quantity Cycle
5: Time Circulation + Quantity Control
R/W 0A00 42561 0
P10.01
Number of Connected Motors 1~8 R/W 0A01 42562 1
P10.02
Desired Run Time of Each Motor
in Minutes
0~65500 min R/W 0A02 42563 0
P10.03
Motor Switch Delay Time During
Increasing Demand
0�0~3600�0 sec R/W 0A03 42564 1�0
P10.04
Motor Switch Delay Time During
Decreasing Demand
0�0~3600�0 sec R/W 0A04 42565 1�0
P10.05
Aux Motor Switch Delay Time
During Fix Amount Circulation in
Seconds
0�0~3600�0 sec ♦ R/W 0A05 42566 10�0
P10.06
Aux Motor Switch Frequency
During Fix Amount Circulation in
Hz
0�00~600�00 Hz ♦ R/W 0A06 42567 60�00
P10.07
Circulative Control Malfunction
Action
0: Turn Off All Aux
1: Keep Aux Running
R/W 0A07 42568 0
P10.08
AUX Motor Stop Frequency 0�00~600�00 Hz ♦ R/W 0A08 42569 0
To Next Page
