Page 4–52
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P2.04 Motor 1 Middle Output Frequency 1
R/W 0204 40517
Range/Units (Format: 16-bit unsigned) Default
0�00~600�00 Hz
• P2�04 value cannot be greater than the value in P0�02, Motor 1
Base Frequency�
• P2�04 value cannot be less than the value in P2�08, Motor 1
Minimum Output Frequency�
3�00
Type Hex Addr Dec Addr
P2.05 Motor 1 Middle Output Voltage 1
♦R/W 0205 40518
Range/Units (Format: 16-bit unsigned) Default
230V: 0�0~240�0V
460V: 0�0~480�0V
23 0V:
GS4-21P0~27P5: 15�0V;
GS4-2010+: 14�0V
46 0V:
GS4-41P0~47P5: 30V;
GS4-4010+: 28�0V
Type Hex Addr Dec Addr
P2.06 Motor 1 Middle Output Frequency 2
R/W 0206 40519
Range/Units (Format: 16-bit unsigned) Default
0�00~600�00 Hz
• P2�06 value cannot be greater than the value in P2�04, Motor 1
Middle Output Frequency 1�
• P2�06 value cannot be less than the value in P2�08, Motor 1
Minimum Output Frequency�
3�00
Type Hex Addr Dec Addr
P2.07 Motor 1 Middle Output Voltage 2
♦R/W 0207 40520
Range/Units (Format: 16-bit unsigned) Default
230V: 0�0~240�0V
460V: 0�0~480�0V
23 0V:
GS4-21P0~27P5: 15�0V;
GS4-2010+: 14�0V
46 0V:
GS4-41P0~47P5: 30V;
GS4-4010+: 28�0V
Type Hex Addr Dec Addr
P2.08 Motor 1 Minimum Output Frequency
R/W 0208 40521
Range/Units (Format: 16-bit unsigned) Default
0�00~599�99Hz
• P2�08 value cannot be greater than or equal to the value in P2�06,
Motor 1 Middle Output Frequency 2�
1�50
Type Hex Addr Dec Addr
P2.09 Motor 1 Minimum Output Voltage
♦R/W 0209 40522
Range/Units (Format: 16-bit unsigned) Default
230V: 0�0~240�0V
460V: 0�0~480�0V
23 0V:
GS4-21P0~27P5: 9�0V;
GS4-2010+: 7�0V
46 0V:
GS4-41P0~47P5: 18�0V;
GS4-4010+: 14�0V
Parameters P2.04~P2.09 are used to establish the V/Hz curve of Motor 1, and are used only with
“Custom” V/Hz parameter settings; when P2.00 is set to 03.
reFer To P2.00 (volTS/herTz SeTTingS, Page 4–49) For oPeraTional inForMaTion For ParaMeTerS P2.04~P2.09.
