Automation Direct DURApulse GS4 User Manual

Chapter 4: AC Drive Parameters
Page 4–73
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Type Hex Addr Dec Addr
P3.15 Multi-Function Input (option card DI14 or PLC X16)
R/W 030F 40784
Range/Units (Format: 16-bit unsigned) Default
See P3�03~P3�16 (page 4–66)
0
This parameter sets the function of Multi-Function Input (DI14).
• DI14 is available only on extension card GS4-06NA�
• Represented by Bit 14 on the “DI Status” (P3�46) bit map�
• NO/NC behavior is controlled by Bit 14 in P3�42�
Type Hex Addr Dec Addr
P3.16 Multi-Function Input (option card DI15 or PLC X17)
R/W 0310 40785
Range/Units (Format: 16-bit unsigned) Default
See P3�03~P3�16 (page 4–66)
0
This parameter sets the function of Multi-Function Input (DI15).
• DI15 is available only on extension card GS4-06NA�
• Represented by Bit 15 on the “DI Status” (P3�46) bit map�
• NO/NC behavior is controlled by Bit 15 in P3�42�
